Components and scoped slots in Vue.js

The challenge

At the end of last month, I attempted to solve a small project while learning Vue.js concepts.

The project required to build a photo slider that used 2 child components in the App.vue. The SwiperSlide below finds itself in a scoped slot.

The slot resides in the Swiper component as you see with v-slot="{ item }".

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13


<!-- App.vue template -->
<template>
  <section>
    <Swiper
      :list="images"
      :index="index"
      v-slot="{ item }"
      @change="index = $event"
    >
      <SwiperSlide v-bind="item" />
    </Swiper>
  </section>
</template>

The challenge that I struggled with was to implement the code so:

the App.vue provided the markup (I didn’t have to change App.vue)
the SwiperSlide child component would be and didn’t need modification:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17


<!-- SwiperSlide.vue template -->
<template>
  <img :src="image" :alt="`Image ${title}`" width="400" height="200" />
</template>

<script setup>
  defineProps({
    image: {
      type: String,
      required: true,
    },
    title: {
      type: String,
      required: true,
    },
  });
</script>

I couldn’t understand how I had to code the Swiper component without touching App.vue and SwiperSlide component.

I read a few times this section of the documentation that described the use case.

How did I make it work

With the following, I completed the task:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38


<template>
  <section class="container">
    <Transition>
      <ul ref="ulElement">
        <li>
          <slot :item="{ ...currentImage }"></slot>
        </li>
      </ul>
    </Transition>
    <button v-show="showPrev" class="prev-slide" @click="prevImage"><</button>
    <button v-show="showNext" class="next-slide" @click="nextImage">></button>
  </section>
</template>

<script setup>
  import { ref, computed, onMounted } from "vue";
  const props = defineProps({
    list: { type: Array, required: true },
    index: { type: Number, required: true },
  });
  const emits = defineEmits(["@change"]);
  const currentImage = computed(() => props.list[props.index]);
  const currentImageIndex = computed(() => props.index + 1);

  const ulElement = ref(null);
  const translate = ref(null);

  const showPrev = computed(() => currentImageIndex.value > 1);
  const showNext = computed(() => currentImageIndex.value < props.list.length);
  const prevImage = () => {
    emits("@change", props.index - 1);
    translate.value = `-${ulElement.value.offsetWidth}px`;
  };
  const nextImage = () => {
    emits("@change", props.index + 1);
    translate.value = `${ulElement.value.offsetWidth}px`;
  };
</script>

First, the prop name on the <slot> element is key: it must match what the parent provides to the slot, in our case it is v-slot="{ item }". So the prop must be named :item.

Second, the actual image object must be destructured so that the props definition in SwiperSlide receive them individually.

If I’m mistaken somewhere, tell me so I can correct the wording, but after trying it out, I’m pretty sure that I now understand how scoped slots work.

Thanks for reading this article.
